Giant Tool Capsule

More than 10 years after its launch, the recipe has changed but the goals remain: quality, efficiency and reliability. Mavic specific technologies ensure enhanced performances on any bike. Completely endorsed by the Crossride – an incredible value! A specific version of the front wheel makes it compatible with 15mm forks.

The hub construction reduces weight and the higher rim profile increases stiffness. Efficient and reliable wheelset thanks to high-end features: QRM bearings and TS-2 freewheel for direct power transfer, Hammer Hardening (H2) spoke holes and Straight pull spokes – stronger than J bent spokes. Unique esthetics will make any bike look better: black, disc brake specific rim profile, large and visible graphics and bladed aero spokes.
The front wheel has 15mm thru-axle. With optionally adapter is it possible to make your front hub compatible with a quick release fork. With the included adapter the rear wheel can be converted to x-12 standard (12x142mm). Also it is convertible to 9mm quick release by an adapter, which must be ordered separatly.

Technologies:
TS-2 (Transfer System 2) Using 2 pawls engaging simultaneously, this freewheel system is also fitted with an alloy monobloc axle that is light and stiff and offers multiple compatibilities.
H2 (Hammer Hardening) – Local strengthening of the rim in the area where the spokes exert the greatest force. This improves life expectancy and the resistance to micro cracking.
QRM (Qualité Roulements Mavic) – Mavic only uses high quality sealed cartridge bearings. On QRM wheels, they feature double sealing (2RS or LLU) together with tight C3 internal clearance. High efficiency thanks to low play and tight tolerances. High durability.
Self Lock – The special shape of the spoke end, on the thread, makes it impossible to loosen. The spoke stays tightly screwed into the nipple, no tension loss is occuring. As a benefit, the wheel keeps its original roundess for a long time, and does not get out of true.

Maintenance/care:
Clean with a dry cloth or soap and water. Do not use pressurized water.

Developed with world’s fastest enduro athletes (Clementz, Chausson), the Crossmax Enduro is 100% developed to maximize the enduro experience. Different rims widths front and rear to accommodate different tire width and tread pattern, unique features to offer the ultimate combination of grip and responsiveness.

Instant acceleration and dynamic handling thanks to very low weight and inertia. ISM interspoke milling, exclusive Maxtal alloy rims and Spokes made of Zicral alloy. Direct power transfer is guaranteed with Mavic’s improved dishes, Isopulse lacing (rear hub) and high quality Fore drilled rims that are compatible to UST tubeless tires.
The front wheel has 20mm thru-axle, 15mm with the delivered adapter. With an optional adapter it is possible to make your front hub compatible with a quick release fork. By removing the 9mm reducer, which is already assembled in the rear hub, the rear wheel can be ride with 12mm thru-axle. With an adapter the rear wheel can be converted to x-12 standard (12x142mm).

Key benefits:
Enduro racing front and rear specific wheel-tire system
– Grip and comfort front : 21mm rim and Crossmax Charge 2.4″ aggressive tire
– Responsiveness rear : 19mm rim and Crossmax Roam XL 2.2″ fast rolling tire
Mavic key technologies – More responsiveness : ISM, Isopulse, UST Tubeless Ready
– Reliability : Maxtal, Zicral, Guard2
– Full compatibility for front and rear hubs
Unique SSC design
– Endorsed and used by pro athletes
– Matching WTS design

Rim technologies:
Fore – By drilling only one rim wall, we made the rim four times more resistant to fatigue stress. All your energy is transmitted through a 40% increase in rigidity.
ITS4 (Instant Transfer System 4) – Using 4 pawls working 2 by 2, the system provides a more dynamic ride, thanks to a very fast engagement. Its versatility makes it compatible with all kind of frame retention system. Better energy transmission: fast engagement, only 7,5° freeplay between two engaged positions. Stiffer: 17mm monobloc axle. 12mm thru-axle compatible to fit any kind of frame retention system.
ISM – Inter Spoke Milling.
Isopulse – This spoke lacing design and mounting brings better wheel stability, a constant spoke tension and a crystal clear transmission of energy.
Maxtal – Exclusive to Mavic. An aluminum alloy that is 30% more resistant than a 6106 alloy for lighter and spicier rims.
SUP (Soudé Usiné Process) – A welded and milled rim joint which is extremely strong, eliminates shuddering when braking and offers superior wheel balance.
QRM+ (Qualité Roulements Mavic Plus) – Mavic Quality Bearings Plus.
Zicral – A highly resistant and lightweight aluminum alloy for spokes.
UST – Universal Standard for tubeless tires.

Tire technologies:
UST Tubeless Ready – The UST concept improves traction, control and comfort while reducing inertia and flats. The ‘tubeless ready’ construction results in a lighter tire for improved performance. Benefits of UST: traction, control, comfort. Tubeless Ready: lighter construction, perfectly air tight with the use of sealant.
Guard² – The strongest tire Dual ply construction makes for a super strong casing to prevent flats even at low pressure. Rubber layers thickness is optimized to keep the weight low. Recommended for enduro racing and all types of aggressive riding.
SCC (Super Contact Compound, Crossmax Charge): The best grip – SCC is the softest compound (40a) and delivers unbelievable grip in all conditions. It gives this extra confidence needed to push our limits.
ARC (All Round Compound, Crossmax Roam XL): All round compound (60 shore A) that makes a versatile and durable tire.
CC (Contact Compound, Crossmax Roam XL): Softer compound (50a) that offers excellent grip in both dry and wet condition while not compromising durability and rolling efficiency.

Maintenance/care:
Clean with a dry cloth or soap and water. Do not use pressurized water.
