Giant Defy 2

Giant Revel: your ticKet to trail ready adventure, this competition inspired rig is ready to carve out your off road quest – acts the part and looks the part.

2013 Giant Revel mens mountain bike features a lightweight AluxX aluminium frame born from Giant’s experience with performance off-road racing – Revel is kitted out with quality trail minded components that make it a reliable companion, with true mountain bike spirit.

FRAME
Sizes: Please call for availability
Colours: Black/Light Green/Silver
Frame: ALUXX-Grade Butted Aluminium
Fork: SR Suntour XCT MLO V4, 80mm, Lock-out
Shock: N/A

COMPONENTS
Handlebar: Giant Sport Alloy low riser, 25.4mm, 25mm rise
Stem: Giant Sport Alloy, 15 degree rise
Seatpost: Giant Sport Forged Alloy, 30.9x375mm
Saddle: Giant Sport Trail
Pedals: Nylon platform w/ steel cage

DRIVETRAIN
Shifters: Shimano SL-M310, 3×8 speed
Front Derailleur: Shimano M191
Rear Derailleur: Shimano Alivio M430
Brakes: Tektro HDC300 hydraulic disc, 160mm rotors
Brake Levers: Tektro HDC300 Hydraulic Disc
Cassette: Shimano HG40 11-32, 8s
Chain: KMC Z-8
Crankset: SR Suntour NEX 24/34/42 w/ chainguard
Bottom Bracket: SR Suntour Sealed Cartridge

WHEELS
Rims: Giant XC alloy, double wall
Hubs: Formula DC20/22 Aluminium Loose Ball Bearing
Spokes: Stainless steel 14G
Tyres: Giant Sport 26×2.1″

There's nothing like the feeling of riding a classic hardtail, except this – trusted XtC design updated for bang up to date 27.5 wheels. Race it, win it, love it.

With its ALUXX SL frameset and 27.5 geometry, the XtC 27.5 blends quickness and control. The proprietary ALUXX SL alloy from Giant's own forging facilities is stiffer and lighter than 6061-series aluminum, while PowerCore – a massively oversized bottom bracket/chainstay area with fully integrated 86mm BB and asymmetric chainstays provide additional stiffness on the driveside and stability on the non-driveside for unprecedented pedalling stiffness.

FRAME
Sizes: Please call for availability
Colors: Black/Blue
Frame: ALUXX SL-Grade Aluminum
Fork: Fox 32 Float CTD Evolution 27.5″, 100mm Travel, QR15, OverDrive 2 Tapered Steerer
Shock: N/A

COMPONENTS
Handlebar: Giant Connect XC, 19mm rise, 690 x 31.8mm
Stem: Giant Connect SL, OverDrive 2, 8 degree rise
Seatpost: Giant Connect SL, 27.2x375mm
Saddle: Giant Contact (Forward)
Pedals: N/A

DRIVETRAIN
Shifters: Shimano XT, 2x10s
Front Derailleur: Shimano XT
Rear Derailleur: Shimano XT Shadow+, 10s
Brakes: Shimano XT, M785
Brake Levers: Shimano XT, M785
Cassette: Shimano HG62 11-36, 10s
Chain: KMC X10 w/ Missing Link
Crankset: Shimano XT 38/26
Bottom Bracket: Shimano Press-Fit

WHEELS
Rims: Giant P-XC2 27.5
Hubs: Giant Tracker, sealed bearings [F] QR15 Thru-Axle, [R] 135×5 QR
Spokes: Stainless, double-butted, black w/ alloy nipples
Tires: Schwalbe Racing Ralph 27.5×2.1″, Folding Performance
