Torpado T595 Earth

Torpado T540 Brave Soul

FRAME
Colours: White
Frame: Full Suspension Aluminium
Fork: Suntour XCT ML0
Shock: Yes

COMPONENTS
Gears: Shimano Alivio
Shifting: Shimano SLM-31D
Chainwheel: Shimano M 171
Freewheel: Shimano MFZ-7
Brakes: Promax Dsk-907
Wheels: Torpado Disk
Tyres: Maxxis 26 x 1.95
Stem: Torpado Aheadset Alu
Handlebar: Torpado ALU FOV
Seat post: Torpado ALU
Saddle: Torpado FT 5207

WANT TO RIDE LIKE DOWNHILL WORLD CHAMPION DANNY HART? YOU CAN START BY GETTING ON HIS BIKE.

At the core of this competition-oriented downhill flyer is an impressively light, strong and agile frameset. The radically hydroformed tubeset utilizes the latest, lightweight co-pivot design to shed grams while maintaining outstanding stiffness and durability

FRAME
Sizes: Please call for availability
Colors: White/Black/Light Blue
Frame: ALUXX SL-Grade Aluminium, 8″ Maestro Suspension
Fork: RockShox BoXXer R2C2, 8″ travel, Coil, adj. beginning and ending-stroke rebound, high and low-speed compression
Shock: RockShox Vivid R2 Air [differs from picture]

COMPONENTS
Handlebar: Giant Contact AM, Low Rise, 750mm, 31.8
Stem: Giant Contact DH, Direct Mount
Seatpost: Giant Contact, 30.9
Saddle: Fi’zi:k Tundra 2 w/ Manganese Rails
Pedals: N/A

DRIVETRAIN
Shifters: SRAM X7, 1×10 Speed
Front Derailleur: N/A
Rear Derailleur: SRAM X9 Type 2, 10-Speed
Brakes: Avid Elixir 7, [F] 200mm [R] 180mm rotors
Brake Levers: Avid Elixir 7
Cassette: SRAM PG1070, 11×26 10-Speed
Chain: KMC X-10
Crankset: Truvativ Descendant 36T w/ MRP G2 Mini SL
Bottom Bracket: SRAM GXP

WHEELS
Rims: DT Swiss EX-500
Hubs: [F] Giant Tracker 20mm Thru-Axle, [R] DT 350 12 mm Thru-Axle, 32h
Spokes: DT Competition, 14/15g
Tires: Schwalbe Muddy Mary, Evolution DH, 26×2.5

GET A FEEL FOR THE TRAIL WITH THIS CLASSIC HARDTAIL MADE FOR ASPIRING SINGLETRACK RIDERS. IT FEATURES LARGER DIAMETER 29-INCH WHEELS THAT GIVE IT ADDED STABILITY ON XC TERRAIN—SO YOU CAN PUSH THE PACE ON CLIMBS AND LET LOOSE ON THE DESCENTS.

Built on a new lightweight ALUXX aluminum frame that features classic hardtail design plus the balanced riding characteristics of either larger diameter 29-inch or 27.5-inch wheels, Talon is a great choice for XC or light trail terrain. The frame geometry is specifically designed to adapt to its respective wheel size and either an 80mm or 100mm suspension fork (depending on frame size). It’s a confident ride that’s perfect for ambitious riders who want to take their off-road skills to the next level.

KEY PERFORMANCE FACTORS

Proven alloy performance – ALUXX aluminum frameset is hand-built in-house by the world leader in aluminum engineering.

Balance and stability – Frame geometry is designed to optimize the balance and roll-over capabilities of 29-inch wheels or the liveliness of 27.5-inch wheels (depending on frame size).

XC control – Suspension fork offers either 80mm or 100mm of smooth travel for added XC control.

Sizes: Please call for sizing
Colours:Hematite
Frame: ALUXX-Grade Aluminum, disc
Fork: SSXC32-2 RL 29, air spring, QR, alloy steerer
Handlebar: Giant Connect Trail, 31.8mm
Stem: Giant Sport, 7-degree
Seat post: Giant Sport, 30.9
Saddle: Giant Custom
Pedals: MTB caged
Shifters: Shimano Deore M4100, 1×10
Front Derailleur: N/A
Rear Derailleur: Shimano Deore M5120
Brakes: Tektro HDC M275, hydraulic, Tektro rotors [F]180mm, [R]160mm
Brake Levers: Tektro HDC M275
Cassette: Shimano Deore M4100, 11×42
Chain: KMC X10
Crankset: ProWheel Charm, 30t (27.5) or 32t (29)
Bottom Bracket: Cartridge
Rims: Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width
Hubs: Alloy, sealed bearing
Spokes: Stainless, 14G
Tires: Kenda Booster 27.5 or 29×2.4″, wire bead
